Features
Specifications
Item
Specification
CPU
32-bit / 200MHz
Memory
8MB Flash
Display
128x32 Graphic LCD(B&W)
Fingerprint Sensor
Optical / 500 DPI
Authentication Media
Fingerprint, Password, RF cards
Authentication Method
1:1, 1:N, shortcut ID
1:1 Verification Time
Less than 1 sec.
1:N Identification Time
Less than 2 sec. (2,000 templates)
Template Capacity
2,000 templates (expandable)
Log Capacity
20,000 logs
Communication
TCP/IP, RS485, Wiegand(26/34bit)
Relay
Deadbolt, EM Lock, Door Strike, Automatic Door
Operating Temperature/humidity
-20~60? / 10~90%
Certificate
CE, FCC
Size
77(W) x 178(H) x 50(D) mm
Product Type
Model
Description
SW101-S
Standard type (Fingerprint & Password)
SW101-R
Low Frequency(125KHz) Card Supported (HID, EM)
SW101-M
High Frequency(13.56MHz) Card Supported (Mifare)
Access Manager
Components
Access Server/Remote Manager/Remote Monitor
Max. No. of Accessible Terminals
ACM Pro.
2.000 EA
ACM v2.57x
255EA
No . of Remote client
8
Supporting OS
Windows 2000 or Above
No . of Max . Registration
10,000 Persons (SQL/SQL Express)
10.000 Persons (MDB/SQL)
