Specifications of the MHS5200C Access Control System:

•   Capability to monitor traffic, open doors, register and delete cards, track duration of stay, and generate various reports via computer.

•   Compatibility with all standard card readers (magnetic/Shetab-compatible, barcode, contactless/RFID, and long-range).

•   Simultaneous connectivity with two contactless readers, one barcode reader, one magnetic reader, and two keypads (1–14 digits). • Suitable for installation on all types of doors: wooden, metal, security, glass, elevator, and safes.

• Power supply: Adapter (Input: 220V AC; Output: 12V DC, up to 3A).

• Option to conceal the card reader behind drywall or stone walls to prevent unauthorized access.

• Compatible with access control software: Online, Offline, and DC Helper.

• Features five sensor inputs for detecting heat, smoke, motion, obstacles, vibration, etc.

• Supports up to 2,000 users and stores 3,000 access records.

• Schedule configuration for defining authorized access times.

• Connects to smart power switches for energy management.

• PC connectivity via TCP/IP and RS232 protocols.

• Control unit and peripheral dimensions: 295 x 196 x 90 mm.

• Alarm system triggered after five unsuccessful attempts.

• Compatible with all electric, magnetic, and bolt locks.

• Supports access via PIN code, card, or a combination of both.

• Connects to vehicle and pedestrian barriers/gates.

• Compatible with the SF620 fingerprint sensor.

• Logs access times in the system memory.

• Connects to fire alarm systems (single zone).

• Supports connection to cameras and remote controls.

• Installation options: Wall-mounted or false ceiling. )

• Battery connection capability

Online Access Control Software Specifications:

• Support for credit-based systems

• Entry and exit reporting

• Financial reporting

• Display of the list of individuals currently present

• Image capture upon entry or exit

• Display of capacity, amount, date, time, etc.

• Connectivity to displays with PC communication ports

• Prevention of duplicate entry (single entry allowed prior to exit)

• Definition of four user types (prepaid, postpaid, open/general, personnel)

Offline Access Control Software Specifications:

• Developed using C#

• SQL Server database

• Online reporting capability

• Online monitoring capability

• Time-based priority settings for gate usage

• Reporting on defined personnel lists •              Generating reports on system entry and exit activity

•              Generating reports for specific time ranges

•              Ability to define an unlimited number of online users

•              Ability to define unlimited work shifts for personnel

•              Ability to configure work calendars for the full 365 days of the year

•              Ability to monitor and control all devices via the software

•              Ability to define individual Solar Hijri work calendars for each staff member

•              Ability to define various users and access levels

•              Ability to issue access permissions for specific dates and times

•              Ability to define up to 2,000 users in offline mode per unit System

•              Capability to network multiple devices and communicate via comprehensive software.
